CAMERA |
| Image Sensor |
4 × 1/2.8″ Progressive Scan CMOS |
| Max. Resolution |
8MP, 3840(H) × 2160(V) |
| Shutter Speed |
1/5 to 1/100,000s |
| Min. Illumination |
Color: 0.005 Lux @ (F1.6, AGC ON)
B/W: 0.001 Lux @ (F1.6, AGC ON), 0 Lux with IR on
|
| Day & Night |
Auto (ICR) |
| Angle Adjustment |
Pan: -180° to 180°, Tilt: 0° to 130°, Rotation: 0° to 355°
|
LENS |
| Lens Type |
Varifocal lens, Motorized focal |
| Focal Length |
2.7 to 13.5 mm |
| Max. Aperture |
F1.6 |
| Field of View (FOV) |
H: 108.0° to 31.4°, V: 56.1° to 17.6° |
| Iris |
Auto Iris |
ILLUMINATOR |
| Type |
IR |
| IR wavelength |
850 nm |
| Distance |
Up to 40 m (131.2 ft) |
| Control |
Auto/Manual |
INTELLIGENT ANALYTICS |
| AI Multi-Target |
Supports face, human, and vehicle detection & capture
Supports human and vehicle attribute detection
Multiple frame modes: Full Frame, Four-Corner Frame, Mosaic
|
| Attribute Extraction |
Human Attributes: Gender, age, glasses, hat, bag, upper clothing color & style, lower clothing color &
style, reflection vest
Vehicle Attributes: Type, color, brand, orientation
|
| Intelligent Analysis |
Intrusion detection, single line crossing, double line crossing, loitering, wrong-way detection, area
people limit, perimeter detection, illegal parking, running detection, fall detection, fight detection,
enter area, leave area – supports accurate target classification (human/vehicle)
|
| People Counting |
Supported |
IMAGE |
| Image Adjustment |
Brightness, Sharpness, Contrast, Saturation adjustable |
| Scene Mode |
Indoor, Outdoor, Mirror, Corridor mode |
| Exposure Mode |
Auto, Manual, Shutter priority |
| White Balance |
Auto, Tungsten, Fluorescent, Daylight, Shadow, Manual |
| Day/Night Setting |
Auto, Day, Night, Timer |
| Noise Reduction |
2D/3D DNR |
| Image Enhancement |
WDR, HLC, BLC, Defog |
| Wide Dynamic Range |
True WDR (120dB) |
| Privacy Masking |
Up to 4 × 4 areas |
EVENT |
| Alarm Triggers |
IVS, Motion detection, Alarm input, Network alarm, Disk alarm, Day/Night switch alarm, Abnormal sound
detection
|
| Event Actions |
Alarm record, Alarm output, FTP upload, SMTP upload, Snapshot, Audible alarm output
|
VIDEO & AUDIO
|
| Number of Streams |
3 Streams
|
| Resolution |
Stream1: 3840 × 2160, 2592 × 1944, 2592 × 1520, 2560 × 1440, 2304 × 1296, 1920 × 1080, 1280 × 720
Stream2: D1, VGA, CIF
Stream3: VGA, CIF, QVGA
|
| Frame Rate |
Up to 25/30fps |
| Bit Rate Control |
CBR/VBR |
| Bit Rate |
Stream1: 200 Kbps to 16 Mbps
Stream2: 100 Kbps to 6 Mbps
Stream3: 100 Kbps to 3 Mbps
|
| Smart Encoding |
Supported |
| Region of Interest (ROI) |
Off / On (8 Zone, Rectangle) |
| Audio Compression |
G.711 A-law, G.711 μ-law, RAW_PCM |
| Audio Bit Rate |
64 Kbps (G.711), 128 Kbps (RAW_PCM) |
NETWORK
|
| Protocols |
IPv4/IPv6, HTTP/HTTPS, DNS, DDNS, DHCP, PPPoE, RTSP/RTCP/RTP, TCP/UDP, NTP, ARP, UPnP, FTP, SMTP, QoS,
ICMP, IGMP, SMTP, 802.1x, SNMP, Multicast
|
| Application Programming Interface |
ONVIF (Profile S/T/G/M), SDK, CGI |
| Max Concurrent Streams |
10 channels |
| User/Host Level |
32+ users, 3 levels: Administrator, Operator, Media user
|
| Web Viewer |
<IE11, Chrome, Firefox, Microsoft Edge |
SECURITY
|
| OS / Firmware Protect |
Encrypted firmware, Secure boot, Signed firmware |
| User Authentication |
Digest authentication, Prevent brute-force attack |
| Network Authentication |
IEEE 802.1X (EAP-TLS) |
| Secure Communication |
HTTPS, WSS(WebSocket Secure), SRTP |
| Access Control |
IP-based access control, Auto logout |
| Data Protect |
Encryption credentials |
| Audit |
Access / System / Event Log management |
| Secure Storage |
SDcard partition encrypt(AES-256), Secure element |
| Supply Chain Security |
SBOM |
INTERFACE
|
| Network Interface |
1 × Ethernet (10/100 Base-T), RJ-45 connector |
| Built-in Microphone |
Supported |
| Audio Interface |
1ch Input, 1ch Output |
| Alarm Interface |
4ch Input, 2ch Output |
| RS-485 |
1 RS-485 |
| CVBS Output |
Supported |
| SD Card Slot |
Built-in microSD card slot, up to 1 TB |
| Reset Button |
Supported |
DORI DISTANCE (EN62676-4 STANDARD)
|
| Detect |
95 to 290 m (311.7 to 951.4 ft) |
| Observe |
38 to 116 m (124.7 to 380.6 ft) |
| Recognize |
19 to 58 m (62.3 to 190.3 ft) |
| Identify |
9.5 to 29 m (31.2 to 95.1 ft) |
GENERAL
|
| Language |
English, Chinese, Traditional Chinese, Polish, Italian, Portuguese, Spanish, Russian, French, Czech,
Hungarian, Japanese, Korean. Default: English
|
| Power Supply |
12 VDC (-15% to +25%) / PoE+ (802.3at) |
| Power Consumption |
Typical: 10.8 W (12 VDC) / approx. 13.5 W (PoE)
Max (IR on): 20.2 W (12 VDC) / approx. 25.3 W (PoE)
|
| Operating Temperature |
-40°C to 60°C (-40°F to 140°F) |
| Operating Humidity |
Less than 95% RH |
| Ingress Protection |
IP67, IK10 |
| Certifications |
CE-EMC
EN 55032, EN IEC 61000-6-4, EN IEC 61000-3-2, EN 61000-3-3, EN 55035, EN 50130-4
FCC 47 CFR Part 15 Subpart B
|
| Material |
Aluminum alloy body, bubble: plastic |
| Dimensions |
Φ282 × 206.3 mm (φ11.1 × 8.12 inch), (Bracket not included)
|
| Net Weight |
Approx. 4 kg (8.82 lb), (Bracket not included) |
