NVR
SPECIFICATIONS |
| Operating System |
Embedded Linux |
| Operating Interface |
Web/operating in local GUI |
AUDIO
AND VIDEO |
| Max bandwidth |
384Mbps |
| IPC Input |
64 channels |
| VGA |
1920×1080,1280×1024,1280×720 |
| HDMI |
3840×2160,1920×1080,1280×1024,1280×720 |
| Audio Output |
1 channel, RCA (Line out,2Vp-p,300ohms) |
| Audio Compression |
G.711A |
| Audio Bit Rate |
64Kbps |
| IP channel Resolution |
Up to 3840×2160 |
| Video decoding |
H.265 (Main Profile@L5.0 High-tie) / H.264 Up to High
Profile@Level5.0 |
| Audio decoding |
G.711A,G711U,G726 |
| Synchronous Playback |
16 channels |
| Decoding Ability |
32CH 1080P@30FPS / 8CH 4K@30FPS |
| Synchronous Preview |
32 |
| Multi-screen Display |
1, 4, 8, 9, 16, 25, 32 views |
| Alarm Linkage |
Record; Snapshot; Buzzer; Log; Preset; Email |
| Two-way Audio / Talk |
Yes |
| Picture Capture |
Support JPEG Capture |
| RECORDING PLAYBACK |
| Record Mode |
Manual; Schedule (general; MD; alarm; intelligent) |
| AI Search |
Search by target classification (human, vehicle, non-motor
vehicle) |
| Backup Method |
USB device |
| Playback Mode |
Play; pause; stop; fast forward; fast backward; rewind; play by frame & Full screen; backup (cutfile);
partially enlarge; audio on/off |
| NETWORK |
| Network Protocol |
HTTP; TCP/IP; IPv4; UPnP; SNMP; RTSP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; DDNS; FTP; P2P; Auto
register |
| Mobile Phone Access |
IOS; Android |
| Interoperability |
ONVIF; SDK |
| Browser |
IE; Edge; Google; Firefox |
| Management Software |
eVMS-BLZ |
AI
FUNCTION – CAMERA |
| AI Motion |
64 channels |
| Object Detection |
64 channels |
| Face Detection |
64 channels |
| Fenced Area Protection |
64 channels |
AI
FUNCTION – NVR |
| Fenced Area Protection |
4 channels |
| Face Recognition |
2 channels |
| Face Detection |
4 channels |
| AI Motion |
8 channels |
| PORTS |
| HDMI |
2 |
| VGA |
1 |
| SATA |
8 |
| ESATA |
1 |
| Max Capacity |
16 TB |
| PoE Ports |
0 |
| Network Interface |
2 RJ-45 (10/100/1000 Mbps) |
| CVBS |
0 |
| USB |
2 USB 2.0 (back panel), 2 USB 2.0 + 1 USB 3.0 (front) |
| RCA Input |
1 |
| RCA Output |
2 |
| Alarm Input |
16 |
| Alarm Output |
8 |
| RS-232 |
1 |
| RS-485 |
1 |
| Reset |
1 |
| GENERAL |
| Front Panel |
CU |
| Packing |
520x520x215mm |
| Dimensions |
2U 441x448x88mm |
| Weight |
7Kg（No HDD） |
| Installation |
Rack or desktop Installation |
| Power Supply |
AC110V~220V±10% 47Hz～63Hz |
| Working Temperature |
–10 °C to +55 °C (14 °F to +131 °F) |
| Working Humidity |
10%–90% (RH) |
| Consumption |
20W (without HDD) |
| Certifications |
CE/FCC |
