Features
NVR Features:
16 Channel with 16 PoE Network Video Recorder
- Embedded LINUX OS
- 16 CH Compact 1U Standalone NVR, 16 PoE Ports Built-in
- Industrial-grade embedded processor
- H.264, H.265, Smart H.264+, and Smart H.265+. H.265 auto switch
- Max. decoding capability: 8 × 1080p@30 fps
- P2P remote surveillance, video play on a mobile device
- VGA/HDMI simultaneous video output, the maximum resolution of HDMI is 4K
- Supports mainstream cameras of ONVIF and RTSP protocols
- AI by Camera:
- Face detection, fenced area protection, IVS, people counting, heat map, and motion detection
* (AI Features only supported when using AI Cameras)
Camera Features:
5MP, 1/2.7” CMOS image sensor, low illuminance
- 5 Megapixel 1/2.7″ CMOS image sensor, low luminance, and high definition image.
- Outputs max. 5 MP (2960 × 1668) @20 fps, and supports 2688×1520 (2688 × 1520) @25/30 fps.
- H.265 codec, high compression rate, ultra-low bit rate.
- Built-in warm light and IR LED, the max. illumination distance is 30 m and the max. warm light distance is 30 m.
- ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.
- Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
- Intelligent monitoring: Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human).
- Abnormality detection: Motion detection, video tampering, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
- IP67 protection.
- Smart Motion Detection Plus.
- AI Functions:
· Fenced Area protection
· AI Motion Detection
· Line Crossing (Person & Vehicle Classification)
Technical Specifications
NVR Model: ENMR3-16POE
System:
Main Processor: Industrial-grade embedded processor
OS: Embedded Linux
Operation Interface: Web/operating in local GUI
Fenced Area Protection by Camera:
Performance: 8 channels
AI Search: Search for pictures by channel, time, and event type
Face Detection by Camera:
Performance: 4 channels
Face Attributes: 6 attributes: Gender, age, glasses, expression, mouth mask, and beard
AI Search: Search for pictures by channel, time, and face attributes
Motion Detection by Camera:
Performance: 12 channels
AI Search: Search by target classification (human, vehicle)
Video:
Access Channel: 16
Network Bandwidth: Access: 160 Mbps; Storage: 1600 Mbps; Forward: 64 Mbps
Resolution: 8MP; 6MP; 5MP; 4MP; 3MP; 1080p; 720p; D1
Decoding Capability: 8 × 1080p@30 fps
Video Output: 1 × VGA output, 1 × HDMI output, supports simultaneous video sources output for VGA & HDMI
Multi-screen Display: 1, 4, 8, 9, 16 views
Alarm:
General Alarm: Motion detection, privacy masking, video loss, scene changing, PIR alarm, IPC external alarm
Anomaly Alarm: Camera disconnection, storage error, disk full, IP conflict, MAC conflict, login locked, and cybersecurity exception
Intelligent Alarm: Face detection, fenced area protection (intrusion and line crossing), IVS, people counting, heat map, and motion detection alarms
Alarm Linkage: Recording, snapshot, audio, buzzer, log, preset, and email
External Port:
Audio Input: 1 × RCA input
Audio Output: 1 × RCA output
HDD: 2 SATA III ports, up to 10 TB for a single HDD. The maximum HDD capacity varies with environment temperature
USB: 2 (1 × front USB2.0; 1 × back USB2.0)
HDMI: 1 (supports up to 4K resolution output)
VGA: 1
Network: 1 × RJ-45, 10/100/1000 Mbps self-adaptive Ethernet port
POE: 16
General Parameter:
Power Supply: 100 V–240 V, 47 Hz–63 HZ, 3.5
Power Consumption: < 10 W (HDD not included, idling). Total output power of PoE is 117W, the maximum output power of a single port is 25.5W
Net Weight: 2.63kg (5.80lb) / Gross Weight: 3.91kg (8.62lb)
Product Dimensions: 375mm × 327.4mm × 53.8mm / (14.76″ × 12.89″ × 2.12″) (W × L × H)
Operating Conditions: –10°C to +55°C (+10°F to +131°F)
Camera Model: MPIX-50T3MAI
Camera:
Image Sensor: 1/2.7” 5Megapixel progressive CMOS
Effective Pixels: 2960 (H) × 1668 (V)
RAM/ROM: 128 MB / 256MB
Min. Illumination: 0.007 Lux@F1.5 (Colour, 30 IRE), 0.0007 lux@F1.5
(B/W, 30 IRE)
Electronic Shutter Speed: Auto/Manual 1/3 s–1/100000 s
IR Distance: 30m (98.43ft-IR); 30m (98.43ft-warm light)
IR On/Off Control: Auto/Manual
IR LEDs Number: 2 (IR LEDs)
Lens:
Max Aperture: F1.6
Focal Length: Fixed 2.8mm lens
Angle of View: Horizontal: 111°; vertical: 58°; diagonal: 132°
Close Focus Distance: 0.8m/2.62ft
Video:
Compression: H.265; H.264; H.264H; H.264B; MJPEG (Only
supported by the sub stream)
Smart Codec: Smart H.265+; Smart H.264+
Resolution:
2960 × 1668 (2960 × 1668); 2880 × 1620 (2880 ×
1620); 2688 × 1520 (2688 × 1520); 3M (2048 ×
1536); 2304 × 1296 (2304 × 1296); 1080p (1920 ×
1080); 1.3M (1280 × 960); 720p (1280 × 720); D1
(704 × 576/704 × 480); VGA (640 × 480); CIF (352 ×
288/352 × 240)
Frame Rate:
Main stream: 2960 × 1668@(1–20 fps)/2688 ×
1520@(1– 25/30 fps) sub stream: 704 × 576@(1–25
fps)/704 × 480@(1–30 fps) *The values above are the
max. frame rates of each stream; for multiple streams,
the values will be subjected to the total encoding
capacity.
BLC Mode: BLC / HLC / WDR(120dB)
Professional Intelligence:
Fenced Area: Protection Line Crossing, Intrusion (Human & Vehicle classification)
Intelligent Search: Work together with Smart NVR to perform refine intelligent search, event extraction, and merging to event videos
Network:
Ethernet: RJ-45 (10/100 Base-T)
Max. User Access: 20 (Total bandwidth: 64M)
Max. User / Host: 20 Users (Total bandwidth: 64 M)
Edge Storage: FTP; SFTP; Micro SD Card (support max. 256GB); WatchNET Cloud; NAS
Electrical:
Power supply: 12V DC/PoE (802.3af)
Power Consumption: Basic: 2.2 W (12 VDC); 2.9 W (PoE) Max. (H.265+ max. resolution + max. stream+ WDR + warm light intensity + IVS): 4.6 W (12 VDC); 5.4 W (PoE)
Operating Conditions: -40°C to +60°C (-40°F to +140°F)
Storage Conditions: -40°C ~ +60°C (-40°F ~ +140°F)
Dimensions: 99.1 mm × Φ121.9 mm (3.9′′ × Φ4.8′′)
Net Weight: 480g (1.06lb) /Gross Weight: 620g (1.37lb)
