Technical Specifications

PNT-0880AILC Specifications:

System:
Main Processor: Embedded Process
Operating System: Embedded LINUX
Face Detection:
Face Detection Performance of AI by Recorder-2 channels, and a single channel can detect up to 12 faces
Face Recognition:
Face Recognition Performance of AI by Recorder-2 channels
Motion Detection:
Motion Detection by Recorder Full-channel Motion Detection (AI by recorder), secondary filtering for human and motor vehicle Motion Detection, reducing false alarms caused by leaves, rain and lighting condition changes
Audio & Video:
Analog Camera Input: 8 channels, BNC: adaptive access by default;
Camera Input:
1. CVI: 8MP, 6MP, 5MP, 4MP, 1080P@25/30 fps, 720P@50/60 fps, 720P@25/30 fps.
2. TVI: 8MP, 5MP, 4MP, 3MP, 1080P@25/30, 720P@25/30 fps.
3. AHD: 8MP, 5MP, 4MP, 3MP, 1080P@25/30, 720P@25/30 fps.
IP Camera Input: 8+8 channels, each channel up to 8 MP
Audio In: 1 RCA (external); 8 BNC (coaxial)
Audio Out:  1 RCA
Encoding Capacity:
All channel 4K(1fps–7fps); 6MP(1 fps–10 fps);
5MP (1 fps–12 fps); 4K-N, 4MP/3MP (1 fps–15 fps);
4M-N/1080P/720P/960H/D1/CIF (1 fps–25/30 fps)
Video Output:
1 HDMI, 1 VGA
HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
Bit Rate: 32 Kbps–6144 Kbps Per Channel
Audio Compression: G.711A/G.711u/PCM
Network Port:
1 (10/100/1000 Mbps Ethernet port, RJ-45)
Audio Input: 1, RCA (external); 8, BNC (coaxial)
Audio Output: 1, RCA
Alarm:
General Alarm: Motion detection, Video Loss, tampering, and local alarm
Anomaly Alarm: No disk, disk error, low space, offline, ip conflict, MAC conflict
Intelligent Alarm: Face detection, face recognition, fenced area protection
Alarm Linkage: Record, snapshot (panoramic), IPC external alarm output, access controller, voice prompt, buzzer, log, preset, email
Playback & Backup:
Playback: 1/4/9
Playback Mode: Instant playback, general playback, event playback, tag playback, smart playback (face and motion detection)
Backup: USB Device/Network
Storage:
1 SATA Port, up to 16TB for a single HDD, the maximum HDD capacity varies with environment temperature
Auxiliary Interface:
USB: 2 USB Ports (1 USB 2.0, 1 USB 3.0)
RS485: 1 Port, for PTZ Control
Electrical:
Power Supply: 12 VDC/2A
Power Consumption: ≤10W

XVI-80IRBT Specifications:

Camera:
Image Sensor: 1/2.7″ 8MP CMOS Image Sensor
Effective Pixels: 2880 (H) × 1620 (V), 5MP
Electronic Shutter Speed: PAL: 1/25s–1/100000s / NTSC: 1/30s–1/100000s
Minimum Illumination: 0.01 Lux/F1.6, 30IRE, 0 Lux IR on
S/N Ratio: More than 65dB
Max IR Distance: 60m (196.9ft)
IR On/Off: Control Auto / Manual
IR LEDs: 2
Lens:
Lens Type: Fixed-focal
Focal Length: 2.8mm fixed
Max Aperture: F1.6
Field of View 132° × 111° × 58° (diagonal × horizontal × vertical)
Close Focus Distance: 0.9m (3.0ft)
Video:
Resolution 5M (2880 × 1620); 4M (2560 × 1440); 1080P (1920 × 1080); 960 H (960 × 576/960 × 480)
Frame Rate:
CVI:
PAL: 5M@25 fps; 4M@25 fps; 1080P@25 fps;
NTSC: 5M@25 fps; 4M@30 fps; 1080P@30 fps
AHD:
PAL: 4M@25 fps;
NTSC: 4M@30 fps
TVI:
PAL: 4M@25 fps;
NTSC: 4M@30 fps
CVBS:
PAL: 960H;
NTSC: 960H
Port:
Audio Interface: One channel built-in mic
Video Output: Video output choices of CVI/TVI/AHD/CVBS by one BNC port
Electrical:
Power Supply: 12V ±30% DC
Power Consumption: Max 5.2W (12V DC, IR on)
Environmental:
Operating Conditions: -40°C ~ +60°C (-40°F ~ +140°F) / <95% (non-condensation)
Storage Conditions: -40°C ~ +60°C (-40°F ~ +140°F) / <95% (non-condensation)
Ingress Protection: IP67
Construction:
Casing: Metal
Dimensions: φ121.9 mm × 99.1 mm (φ4.8″ × 3.9″)
Net Weight: 0.4kg (0.88lb) / Gross Weight: 0.6kg (1.32lb)
