WAC-4D4TOS-ENC

Features

  • Supports RS232/RS485/TCP/IP
  • Cards holder capacity: 30,000 / 100,000 (online mode)
  • Transactions storage: up to 270,000
  • Supports keypad readers for requiring a PIN when entering a door
  • Supports up to 500 temporary cards with security settings
  • Up to 365 holidays
  • 15 Time Zones for each door
  • 24 sets of Flow Control
  • Local and Global Anti-Pass back
  • Programmable Door Status
  • Always Closed (Can be opened by Supervisor cards only)
  • Multiple types of Events
  • Data can be kept for 180 days without power
  • CE, FCC, RoHS approval

Technical Specifications

Description 4 Door 4 Reader
Number of Readers 4
Card holders 100,000
Memorized events 270,000
Built-in Auxiliary Input 2
Built-in Auxiliary Output 2
Built-in Lock Output 4
Exit button Inputs 4
PCB size 17cm x 13cm / 6.7” x 5.1”
PCB weight 0.5 Kg
CPU 32 bits of ARM, 2 watch-dogs
Memory 32 KB ROM / 512KB SRAM
Card/Transactions capacity 100,000 card holders, 270,000 off line event buffer, Unlimited transactions (on line)
Reader Supports Wiegand 24 to 72 bits (Fingerprint reader, EM/Mifare reader)
Supports WatchNET and other readers with Wiegand Protocol
Communication TCP/IP 10 Mbps (optional)
127 controllers for each RS485
Up to1,200 m for each RS485
Communication speed:19,200/9,600/4,800 1,1,n
Can be worked with WAE-016 controller and WAI-168
Input/output port RJ45 Socket for Plug & Play connection of readers
Dry door relay/extension relays output, 5A
Exit Buttons, Door Lock Sensors, Extension Inputs
Protection circuit Protects the board from over voltage and short circuit
Auto-test Yes
Led indicator light Yellow: power; red and green: communication
Power 12VDC (±30%), 300mA
Power over Ethernet
Work environment Temperature -40Deg C ~ 70Deg C / 40Deg F ~ +158Deg F / Humidity: 0 to 90%
Package Metal housing with power supply
Dimension 40.3cm x 38.4cm x 7.2 cm / 15.8” x 15.1” x 2.8”
Weight 4.5kg / 9.92lb
