PNT-32EXAIR2

Features

• 32 CH 4K 2U Embedded LINUX processor
• H.265+/H.265 dual-stream video compression
• Penta-Brid Supports HDCVI/XVI/AHD/TVI/CVBS/IP video inputs
• Max 32 channels IP/HD Analog camera inputs, each channel up to 12MP;
Max 128 Mbps incoming bandwidth
• 8 SATA Ports, up to 10TB capacity for each disk
• IoT & POS functionalities

AI Functions:
(Supported only on BNC inputs), 2.1MP or higher camera recommended
Fenced Area Protection:
– Up to 6 channels video stream fenced area protection
(Analog channels only), 10 IVS for each channel
– Human/Vehicle secondary recognition for line crossing and intrusion
– AI Search by target classification (Human, Vehicle)
Face Recognition:
– Up to 6 channels video stream human face recognition
(Analog channels only), max 12 face pictures/sec processing
– Detect strangers’ faces (not in device’s face database)
– Up to 8 target face images search at same time, similarity
threshold can be set for each target face image
– Up to 10 face databases with 20,000 face images in total
Name, gender, birthday, address, certificate type, certificate No.,
countries & regions and state can be added to each face picture
– Buzzer, Voice Prompts, Email, Snapshot, Recording,
Alarm Out, PTZ Activation, etc.
AI Motion Detection:
– Up to 32 channels video stream motion detection
(Analog channels only)
– AI Search by target classification (Human, Vehicle)

Technical Specifications

Model PNT-32EXAIR2
System Main Processor Embedded Processor
Operating System Embedded LINUX
Fenced Area Protection Performance 6 channels, 10 IVS for each channel
Only Analog Cameras Supported
Object classification Human/Vehicle secondary recognition for line
crossing and intrusion
AI Search Search by target classification (Human, Vehicle)
Face Recognition Performance 6 channels, max 12 face pictures/sec processing
Only Analog Cameras Supported
Stranger Mode Detect strangers’ faces
(not in device’s face database)
Similarity threshold can be set manually
AI Search Up to 8 target face images search at same time,
similarity threshold can be set for each target
face image
Database
Management		 Up to 10 face databases with 20,000 face images
in total. Name, gender, birthday, address,
certificate type, certificate No., countries & regions
and state can be added to each face picture
Database Application Each database can be applied to video channels
independently
Trigger Events Buzzer, Voice Prompts, Email, Snapshot,
Recording, Alarm Out, PTZ Activation, etc.
AI Motion Performance 32 channels
Only Analog Cameras Supported
AI Search Search by target classification (Human, Vehicle)
Video and Audio Analog Camera Input 32 channels, BNC
HDCVI Camera Input 4K, 6MP, 5MP, 4MP, 1080P@25/30fps,
720P@50/60fps, 720P@25/30fps
AHD Camera Input 4K, 5MP, 4MP, 3MP, 1080P@25/30fps,
720P@25/30fps
TVI Camera Input 4K, 5MP, 4MP, 3MP, 1080P@25/30fps,
720P@25/30fps
CVBS Camera Input PAL/NTSC
IP Camera Input 32 channels, each channel up to 12MP
Audio In/Out 16/1, BNC
Two-way Talk 1 Mic In, 1 Mic Out, BNC
Recording Compression AI Coding/H.265+/H.265/H.264+/H.264
Resolution 4K, 6MP, 5MP, 4K-N, 4MP, 3MP, 4M-N, 1080P,
720P, 960H, D1, CIF
Record Rate Main stream: All channel 4K(1fps-7fps);
6MP(1fps-10fps); 5MP(1fps–12fps); 4K-N, 4MP/3MP(1fps–15fps);
4M-N/1080P/720P/960H/D1/CIF (1fps-25/30fps);
Sub stream:
960H(1fps-15fps); D1/CIF(1fps-25/30fps)
Bit Rate 32 Kbps–6144 Kbps Per Channel
Record Mode Manual, Schedule (General, Continuous), MD
(Video detection: Motion Detection, Video Loss,
Tampering), Alarm, Stop
Record Interval 1 – 60 min (default: 60 min), Pre-record: 1 s–30 s,
Post-record: 10 s–300 s
Audio Compression G.711A, G.711U, PCM
Audio Sample Rate 8 KHz, 16 bit Per Channel
Audio Bit Rate 64 Kbps Per Channel
Display Interface 2 HDMI, 1 VGA, 1 TV
Resolution HDMI: 3840 x 2160, 1920 x 1080, 1280 x 1024, 1280 x 720
VGA: 1920 x 1080, 1280 x 1024, 1280 x 720
Multi-screen Display 1/4/8/9/16/25/36
OSD Camera title, Time, Video loss, Camera lock,
Motion detection, Recording
Network Interface 2 RJ-45 Ports (1000 Mbps)
Network Function HTTP, HTTPS, TCP/IP, IPv4/IPv6, Wi-Fi,
3G/4G, SNMP, UPnP, RTSP, UDP, SMTP,
NTP, DHCP, DNS, IP Filter, PPPoE, DDNS,
FTP, Alarm Server, P2P,IP Search (Supports
WatchNET IP camera, DVR, NVS, etc.)
Max. User Access 128 users
Smart Phone iPhone, Android
Interoperability ONVIF 16.12, CGI Conformant
Video Detection and Alarm Trigger Events Recording, PTZ, Tour, Video Push, Email,
FTP, Snapshot, Buzzer and Screen Tips
Video Detection Motion Detection, MD Zones: 396 (22 × 18),
Video Loss, Tampering and Diagnosis
Alarm input 16
Relay Output 6
Playback and Backup Playback 1/4/9/16
Search Mode Time /Date, Alarm, MD and Exact Search
(accurate to second)
Playback Function Play, Pause, Stop, Rewind, Fast Play, Slow
Play, Next File, Previous File, Next Camera,
Previous Camera, Full Screen, Repeat,
Shuffle, Backup Selection, Digital Zoom
Backup Mode USB Device/Network
Storage Internal HDD 8 SATA Ports, up to 10TB capacity for each disk
eSATA 1 Port
Auxiliary Interface USB 4 USB Ports (2 USB 2.0 , 2 USB 3.0)
RS485 1 Port, for PTZ Control
RS232 1 Port, For PC Communication & Keyboard
Electrical Power Supply AC100V-240V, 50/60Hz
Power Consumption <30W (Without HDD)
Construction Dimensions 2U, 440mm × 463mm × 95mm
(17.32” × 18.23” × 3.73”)
Net Weight 7.0kg (15.5lb) (without HDD)
Gross Weight 9.6kg (21.1lb)
Installation Desktop/racket mounted
Environmental Operating Conditions -10C~+55C / +14F~+131F, 0~90% RH
Storage Conditions -20°C ~ +70°C (-4°F ~ +158°F), 0~90% RH
